Cat 6 Loaded Patch Panel Supplier

Cat 6 Loaded Patch Panel

Cat 6 Loaded Patch Panel Supplier

Product Description

Suitable for 22-26 AWG stranded and solid wire, Cat 6 Loaded Patch Panel are six port RJ45 modules that work with both 110 and Krone punch down tools. With an optional Cable Management bar that terminates four pairs of Cat 6 Loaded Patch Panel offer enhanced Cable Management. National Agencies is a reliable supplier of high-quality Cat 6 Loaded Patch Panel, serving customers across Kolkata, West Bengal, Odisha, Bihar, Jharkhand, Chhattisgarh, and Assam.

The modular Category 6 Snap-in Fit patch panels from National Agencies provide a variety of installation choices and excellent performance. The very effective National Agencies Snap-in keystone jack is used in the Cat 6 Loaded Patch Panel. These patch panels may be attached straight to a 19-inch relay rack or cabinet that meets EIA standards and provide easy-to-use termination, labelling, and cable management features. Cables are correctly guided to the termination point by the rear cable management.

Features of Cat 6 Loaded Patch Panel

  • IDC-compatible six-port RJ45 modules that work with the 110 and Krone tools
  • Terminating four unshielded cable pairs, 22–26 AWG
  • An optional cable management bar for better cable management
  • Colour-coded universal labels for T568A and T568B wiring systems
  • Including the younger generation Quick-Fix for automatic mounting on cabinet or enclosure risers (no screws needed)
  • Any cabinet or enclosure can have universal mounting installed.
  • Each connector is automatically earthed by the panels.
  • To hold the cables when performing maintenance, it has a rear cable guide.
  • Six RJ 45 LCS3 quick-connect connectors (no tools needed), four cassettes of six cats, and 568 A/B marking accompanied with a colourful label with a number


Specifications of Cat 6 Loaded Patch Panel

Identification:

  • ID Plate: PC, transparent color with paper
  • Panel: SPCC, 1.5mm thickness with black color
  • RJ45 Jack
  • Housing:PBT +Glass fiber UL94V-O
  • Contact Brackets: PBT + Glass fiber UL94V-0, black colour


RJ45 Jack Contact

  • Material: Phosphor bronze with nickel plated
  • Finish: 50 micro-inch Gold plated on plug contact area


IDC

  • Housing: PC, UL 94V-0
  • Terminal: phosphor bronze with tin plated


Jack bracket set:

  • ABS


Support Bar

  • SPCC, 1.5mm thickness with Black colour painted
